Alien Hydroponics V-SYSTEM Vortex Water Pump 1100W 120V 17700 l/h

Quick Spec: 1100W | 120V | 17,700 l/h flow rate | SKU: BD101-5012 | $420.00 USD

Precision Control in Any Space

Every irrigation system has a weak link, and in most craft operations that weak link is the pump. When flow rates are inconsistent — surging under load, dropping off mid-cycle, or simply undersized for the reservoir volume — the entire feed program becomes unreliable. Nutrient solution arrives at the wrong concentration, at the wrong time, or not at all. Root zones dry unevenly. Canopy response diverges. The operator compensates manually, adjusting schedules and chasing symptoms rather than running a repeatable process. The equipment is not working with you; it is generating variance that compounds with every irrigation cycle.

After integrating a properly rated pump into the system, the irrigation infrastructure behaves predictably. Reservoir drawdown follows a known schedule. Top-feed lines deliver consistent pressure across every emitter. Drain-to-waste cycles complete on time without residual pooling or dry zones. The operator stops troubleshooting flow and starts managing the crop. Scheduling becomes a fixed variable rather than a daily negotiation with underperforming equipment.

The V-SYSTEM Vortex Water Pump achieves this through a 1100W motor operating on standard 120V infrastructure, producing a verified flow rate of 17,700 l/h — sufficient to service high-volume reservoir systems and multi-zone top-feed arrays without pressure drop across the distribution network. The vortex pump architecture maintains consistent hydraulic output under the variable head pressures common in vertically staged or multi-tier irrigation configurations. In practical terms, the V-SYSTEM Vortex Water Pump delivers 17,700 l/h of sustained flow at 1100W draw on a 120V circuit, providing the hydraulic capacity to anchor a full-scale craft irrigation system without supplemental pumping stages.

Where This Belongs (and Doesn't)

Electrical installation must comply with local codes. Confirm circuit capacity before deployment. This pump draws 1100W at 120V — verify dedicated circuit availability with a licensed electrician before connecting to existing infrastructure.

How It Works

The V-SYSTEM Vortex Water Pump operates on a vortex impeller design, which distinguishes it from standard centrifugal pump architectures. In a vortex configuration, the impeller sits recessed within the pump casing rather than directly in the flow path. This geometry creates a rotating fluid vortex that draws liquid through the pump body without the impeller making direct contact with the primary flow stream. The practical result is a pump that handles particulate-laden nutrient solution — including undissolved mineral content common in hard-water reservoirs — without the clogging and impeller wear that degrades standard centrifugal units over time.

At 1100W on a 120V circuit, the motor delivers the torque necessary to sustain 17,700 l/h across the variable head pressures introduced by vertical lift, long distribution runs, and multi-emitter top-feed manifolds. The 120V operating voltage means the pump integrates directly into standard facility electrical infrastructure without requiring dedicated 240V circuits or transformer stages. Flow output remains consistent across the operating range, providing the hydraulic stability that irrigation scheduling depends on. In practical terms, the V-SYSTEM Vortex Water Pump delivers 17,700 l/h at 1100W on 120V, with a vortex impeller architecture that sustains rated output in nutrient-solution environments without the particulate sensitivity of standard centrifugal designs.

Commercial Assurance

System Integration

• Reservoir Sizing: Match reservoir volume to pump flow rate — at 17,700 l/h, the system requires sufficient reservoir capacity to prevent rapid drawdown and dry-run risk during extended irrigation cycles
• Distribution Manifold: Use appropriately rated PVC or HDPE manifold and fittings sized for the pump's output pressure to prevent joint failure and flow restriction
• Timer and Controller Compatibility: Integrate with a dedicated irrigation timer or controller rated for 1100W resistive load at 120V to enable automated cycle scheduling
• Inline Filtration: Install a pre-pump strainer or inline filter on the intake side to protect the impeller from large debris while preserving the pump's native particulate tolerance
• Electrical Circuit: Dedicate a 15A or 20A 120V circuit to this pump; do not share the circuit with other high-draw equipment to prevent nuisance tripping and voltage sag

Facility Integration Data

The table below provides a reference framework for operators evaluating the V-SYSTEM Vortex Water Pump across single-unit and multi-unit facility deployments, including electrical load aggregation and capital cost at MAP pricing.

Operator Field Notes

• Verify circuit capacity before installation: At 1100W on 120V, this pump draws approximately 9.2A continuous — confirm your circuit breaker and wiring gauge are rated for sustained load before connecting
• Prime the pump before first run: Ensure the pump body is fully submerged and the intake is clear of air pockets before energizing — dry-starting a submersible pump will damage the seal and void any applicable warranty
• Monitor reservoir level during operation: At 17,700 l/h, reservoir drawdown is rapid — install a float switch or low-level cutoff to protect the pump from running dry during extended drain-to-waste cycles
• Inspect intake strainer on a scheduled basis: Even with vortex impeller tolerance for particulates, accumulated debris on the intake screen will reduce effective flow rate and increase motor load over time
• Account for head pressure in system design: Rated flow of 17,700 l/h is measured at zero head — actual delivered flow will be lower as vertical lift and distribution run length increase; size your manifold accordingly
• Local pickup available: If you are evaluating this unit for an active build, in-person pickup at the Longmont location allows for same-day integration — contact Cannafull Spectrum Solutions to confirm availability before visiting

Operator FAQ

Shipping & Logistics

• Shipping Territory: Cannafull Spectrum Solutions ships within the contiguous 48 United States only. Orders outside this territory cannot be fulfilled through this listing.
• Local Pickup: Available at our Longmont, Colorado location. Contact us to confirm stock before visiting. Pickup orders are not subject to shipping charges.
• Returns: Returns are accepted subject to product condition and return authorization. Contact Cannafull Spectrum Solutions within the applicable return window to initiate a return request. Items must be in original, uninstalled condition to qualify.
• Restocking Fee: Returns of non-defective items are subject to a restocking fee of up to 25% per our Return Policy. Review full terms at cannafullspec.com/pages/return-policy before ordering.

Questions about shipping, availability, or order status? Contact Cannafull Spectrum Solutions directly before placing your order.

What's in the Box

• 1x V-SYSTEM Vortex Water Pump 1100W 120V (SKU: BD101-5012)

Note: Included accessories, mounting hardware, fittings, and documentation are not specified in available source data. Contact Cannafull Spectrum Solutions or refer to manufacturer packaging documentation to confirm complete box contents before installation planning.

Regional Compliance & Deployment Notes

• Electrical Code Compliance: Installation of this pump must comply with the National Electrical Code (NEC) and applicable local amendments. Dedicated circuit requirements, GFCI protection in wet locations, and conduit specifications vary by jurisdiction — verify requirements with a licensed electrician before installation.
• Licensed Facility Use: This product is sold for use in licensed commercial production facilities operating under applicable state and local regulations. Operators are responsible for ensuring their facility's water and electrical systems meet the requirements of their operating license.
• State-Level Electrical Inspection: Some states require electrical inspection and permit for new circuit installations associated with commercial equipment. Confirm permit requirements with your local authority having jurisdiction (AHJ) before proceeding.
• Water System Regulations: Irrigation and reservoir systems in licensed production facilities may be subject to water use reporting, discharge regulations, or runoff containment requirements depending on state and municipal rules. Operators are responsible for compliance with applicable water management regulations.
• Shipping Jurisdiction: This product is available for sale and shipment within the contiguous 48 United States only through Cannafull Spectrum Solutions.

Cannafull Spectrum Solutions provides this compliance information as a general reference only. It does not constitute legal or engineering advice. Operators are solely responsible for ensuring their installations meet all applicable federal, state, and local regulatory requirements. Consult qualified legal, electrical, and compliance professionals for jurisdiction-specific guidance.
