Alien Hydroponics V-SYSTEM 16 Pot Kit

Precision Control in Any Space

Every production room has a version of the same problem: the irrigation infrastructure was never designed to keep up with the plants. Reservoirs run inconsistent volumes. Feed lines deliver different concentrations to different positions. Manual top-off introduces timing gaps that compound across a crop cycle. The result is not a single catastrophic failure — it is a slow, invisible erosion of uniformity that shows up at harvest as weight variance, inconsistent density, and the kind of run-to-run unpredictability that makes scaling impossible. Guesswork and equipment that fights you are not problems you solve once; they are costs you pay every cycle until the system underneath the plants is rebuilt from the ground up.

After deployment, the production room operates differently. All 16 plants draw from a shared, recirculating reservoir architecture that maintains consistent nutrient concentration across every position simultaneously. The float valve handles automatic top-off without operator intervention. Venturi injectors saturate the solution with dissolved oxygen continuously, eliminating the dissolved-oxygen deficit that typically requires a separate air pump and its associated failure points. Inspection covers allow visual confirmation of root zone status without disturbing the canopy. The aisle configuration option means every plant in the system is reachable without repositioning rows — access is built into the layout, not worked around it.

The mechanism behind that outcome is a purpose-engineered recirculating DWC architecture built around 16 square net pot positions arranged across 4 rows, each V-Pot holding 15 gallons (58L) of solution. The system's total fluid volume is 256.8 gallons (972 liters), circulated through 5" spiral tubing and 5" Dual-Flow™ fittings via the JET-STREAM® Vortex™ pump. Oxygen delivery is handled entirely by integrated venturi injectors — no external air pump is required. T304 stainless steel clamps, push-fit feed connections, and food-grade silicone grease throughout the assembly ensure that the fluid path is sealed, corrosion-resistant, and serviceable without specialized tooling. Four distinct layout configurations (MIH, MOL, MOR, MSP) allow the system footprint to be matched to the room rather than the room being adapted to the system. In practical terms, the Alien V-SYSTEM 16 Pot Kit delivers recirculating DWC irrigation to 16 plants across a 4-row layout with a 972-liter total fluid volume and zero air pump dependency.

Where This Belongs (and Doesn't)

Note: Facility plumbing connections, water supply lines, and electrical infrastructure for pumps must be installed and verified by licensed tradespeople in accordance with local codes. This system does not include a pump power supply, nutrient dosing equipment, or environmental controls. Confirm room dimensions against your selected layout variant before ordering.

How It Works

The V-SYSTEM 16 Pot Kit is built around a recirculating deep water culture architecture in which nutrient solution is continuously circulated through all 16 V-Pot positions via the JET-STREAM® Vortex™ pump. Each V-Pot holds 15 gallons (58L) of solution, and the system's total fluid volume across all pots and connecting infrastructure is 256.8 gallons (972 liters). Solution moves through 5" spiral tubing — 19 pieces of 5" Silver Spiral 80cm pipe — connected by 5" Dual-Flow™ fittings and sealed with T304 stainless steel clamps (42x 5" stainless steel clamps per kit). The fluid path is assembled using push-fit feed connections, eliminating threaded joints at high-frequency service points.

Oxygen delivery is handled by integrated venturi injectors — 16 venturi fittings and 16 Venturi Air Inlet Pipes (6mm Blue, 2x4" configuration) — which draw air into the solution stream passively as the pump circulates fluid. This eliminates the need for a separate air pump entirely. The float valve assembly provides automatic top-off, maintaining solution level within the system without manual intervention between feed cycles. Total-drainage bases allow the entire system to be emptied completely between cycles without residual pooling. Integrated filtration protects the pump and feed lines from particulate accumulation. Inspection covers on each V-Pot lid allow root zone monitoring without canopy disturbance.

The four layout variants — MIH (99¼" L), MOL (118¼" L), MOR (116¾" L), and MSP (115⅛" L) — all share an identical width of 87¾" and differ only in the length dimension driven by header and pump placement configuration. All variants support the aisle configuration option, which positions rows to create a center aisle for complete bilateral plant access. The distribution architecture uses a 40mm Distribution Tee (1x), 32mm and 40mm straight tank connectors, 22mm rigid pipe (16x 100cm pieces), and 32mm and 40mm spiral pipe to route solution from the central reservoir to each row. Assembly tooling — including a wrench for the float valve, an 8mm screwdriver and socket for 5" clamps, and a dedicated 5" wrench — is included in the kit. In practical terms, the Alien V-SYSTEM 16 Pot Kit circulates 972 liters of nutrient solution across 16 positions in a 4-row layout using venturi-driven oxygen injection and a float-valve-automated top-off system, with no external air pump required.

Configuration Decoder — Layout Variants

All four variants of the Alien V-SYSTEM 16 Pot Kit share identical V-Pot capacity, row count, total fluid volume, and component counts. The only differentiating dimension is system length, which is determined by header and pump placement. Select the variant whose length best matches your room's available run dimension.

All variants: 16 V-Pots | 15 gal (58L) each | 4 Rows | 256.8 gal / 972L total fluid volume | Identical component counts across all configurations.

Commercial Assurance

• Authorized Distribution: Cannafull Spectrum Solutions is a factory-authorized dealer for the Alien V-SYSTEM product line. Every unit ships as a complete, manufacturer-configured kit.
• Component Completeness: Every kit includes all assembly tooling — float valve wrench, 8mm screwdriver, 8mm socket, and 5" wrench — so the system can be commissioned without sourcing additional hardware.
• Warranty: Warranty terms are not specified in available manufacturer source data. Contact Cannafull Spectrum Solutions directly at the time of purchase for current warranty documentation applicable to your order.
• U.S. Support Infrastructure: Local customer service, stocking, and technical support are available for licensed U.S. facilities. Contact our team for pre-sale configuration guidance and post-sale commissioning support.
• Financing Available: Qualified operators may be eligible for financing from $532.21/mo. Contact Cannafull Spectrum Solutions for current financing terms and qualification requirements.

System Integration

• Water Supply: The float valve automatic top-off system requires a pressurized water supply connection at the reservoir. Confirm supply line routing and shutoff valve placement before finalizing room layout.
• Pump Power: The JET-STREAM® Vortex™ pump requires an electrical connection. Pump power specifications should be confirmed with the manufacturer; electrical circuits must be installed by a licensed electrician to applicable code.
• Nutrient Dosing: This system does not include automated nutrient dosing hardware. EC and pH management must be handled via separate dosing equipment or manual protocol integrated into the facility's feed schedule.
• Drainage: Total-drainage bases require a floor drain or collection system capable of handling full system volume (256.8 gallons / 972 liters) during drain-down cycles. Confirm drain capacity before installation.
• Environmental Controls: Reservoir temperature management is not included in this kit. Facilities operating in environments where solution temperature requires active control should plan for a compatible chiller connection — the kit includes 1" cap fittings for chiller connections (2x) and a threaded tank connector 1" (1x).

Facility Integration Data

The table below models per-unit capital deployment across fleet sizes at the listed price of $5,896.53 USD per kit, providing a reference for procurement planning at the facility level.

Capital outlay figures are calculated at listed retail price. Volume pricing may be available for multi-unit orders. Contact Cannafull Spectrum Solutions for fleet procurement terms.

Operator Field Notes

• Select your layout variant before ordering. The four variants (MIH, MOL, MOR, MSP) differ only in system length — from 99¼" to 118¼". Measure your room's available run dimension and confirm clearance for your preferred header and pump placement before placing an order. Variant selection cannot be changed after shipment.
• Plan the aisle configuration at layout stage. The system supports a center-aisle arrangement for bilateral plant access. This configuration affects row spacing and must be accounted for in room layout planning before installation begins — it is not a post-installation adjustment.
• Confirm drain capacity before commissioning. Total-drainage bases will discharge the full system volume of 256.8 gallons (972 liters) during drain-down. Verify that your floor drain or collection system can handle this volume without backup before running the first drain cycle.
• Chiller connection ports are included but not activated by default. The kit includes a threaded tank connector 1" and two 1" cap fittings for chiller connections. If solution temperature management is required for your facility, plan chiller integration before filling the system — retrofitting after commissioning requires a full drain-down.
• Food-grade silicone grease is included — use it on every seal. The kit includes silicone grease for assembly. Apply it to all gaskets and O-rings during initial assembly. Dry assembly of seals is the most common source of slow leaks in recirculating DWC systems.
• All assembly tooling is in the kit. The float valve wrench, 8mm screwdriver, 8mm socket, and 5" wrench are included. No additional tools are required for standard assembly and commissioning.

Operator FAQ

Shipping & Logistics

• Free Shipping: Free shipping is available to the contiguous 48 United States. Shipments outside the contiguous 48 states are not available through Cannafull Spectrum Solutions.
• Freight Considerations: The V-SYSTEM 16 Pot Kit ships as a multi-component kit. Confirm receiving dock access and handling capacity before your order ships. Contact our team for freight class and pallet configuration details.
• Returns: Returns are accepted subject to our Return Policy. Items must be unassembled and in original manufacturer packaging. Contact Cannafull Spectrum Solutions before initiating any return.
• Restocking Fee: Returns of non-defective items are subject to a restocking fee of up to 25% per our Return Policy. Review full terms at cannafullspec.com/pages/return-policy before ordering.

Questions about shipping, freight routing, or delivery timelines? Contact Cannafull Spectrum Solutions directly before placing your order.

What's in the Box

The following components are confirmed in the Alien V-SYSTEM 16 Pot Kit (SKU: BD100-0416) based on manufacturer source data. All quantities are per kit.

• 16x Square Net Pot
• 2x Clamp Size 2
• 12x Clamp Size 3
• 42x 5" Stainless Steel Clamp (T304)
• 1x Hosetail 16mm–3/4" Female Green
• 16x Pipe 22mm Gray Rigid 100cm Piece
• 1x Pipe 32mm Red Spiral 100cm Piece
• 6x Pipe 40mm Silver Spiral 100cm Piece
• 19x Pipe 5" Silver Spiral 80cm Piece
• 40x 22mm Insert for 22mm Rigid Pipe
• 17x Washer 5" Green Silicone
• 1x Tank Connector Straight 32mm
• 1x Tank Connector Straight 40mm
• 1x Distribution Tee 40mm
• 4x Silicone Grease — Food Grade
• 2x Threaded Tank Connector 1"
• 2x 1" Cap for Chiller Connections
• 1x Drain Tap 1/2"–16mm Barb
• 16x Venturi Air Inlet Pipe 6mm Blue (2x 4")
• 16x V-Pot Lid Inspection Cover
• 16x Venturi Fitting
• 1x Wrench for Float Valve
• 1x 8mm Screwdriver for 5" Clamp
• 1x 8mm Socket for 5" Clamp
• 1x Wrench 5"
• JET-STREAM® Vortex™ Pump (1x — included as part of complete kit)
• Float Valve Assembly (1x — included as part of complete kit)

Note: Component list is based on manufacturer source data for SKU BD100-0416. Nutrient dosing equipment, environmental controls, grow media, and pump power supply are not included. Verify complete packing list against the manufacturer's included documentation upon receipt. Contact Cannafull Spectrum Solutions immediately if any components are missing or damaged.

Regional Compliance & Deployment Notes

• U.S. Deployment Only: Cannafull Spectrum Solutions ships the Alien V-SYSTEM 16 Pot Kit within the contiguous 48 United States only. This product listing does not cover shipments to Alaska, Hawaii, U.S. territories, or any international destination.
• Electrical Compliance: Pump and float valve electrical connections must be installed in compliance with the National Electrical Code (NEC) and applicable state and local electrical codes. All electrical work must be performed by a licensed electrician.
• Plumbing Compliance: Water supply connections for the float valve top-off system must comply with applicable state and local plumbing codes. Backflow prevention requirements vary by jurisdiction — confirm with your licensed plumber before installation.
• Facility Licensing: This system is sold for use in licensed commercial cultivation facilities. The operator is solely responsible for ensuring that the facility's cultivation license, water use permits, and any applicable environmental discharge permits are current and in compliance with state and local regulations.
• Drainage and Discharge: Drain-to-waste discharge from this system may be subject to state or local wastewater regulations. Confirm discharge compliance with your facility's environmental compliance officer before commissioning drain cycles.
• Warranty and Support: Warranty terms are not specified in available manufacturer source data. Contact Cannafull Spectrum Solutions for current warranty documentation before purchase.
