Alien Hydroponics V-SYSTEM 4 盆套装
Alien Hydroponics V-SYSTEM 4 盆套装 已缺货，一旦有货将立即发货。
Unlock Trade Pricing
Join our commercial tier for bulk pricing and inventory alerts.
Alien Hydroponics V-SYSTEM 4 盆套装
Alien Hydroponics V-SYSTEM 4 盆套装 已缺货，一旦有货将立即发货。
描述
描述
The Alien V-SYSTEM 4 Pot Kit is a four-vessel Deep Water Culture irrigation system configured in a 2-row layout, engineered for craft operators who require direct nutrient distribution and maximum oxygen saturation in a compact, controlled cultivation environment — replacing fragmented, single-pot reservoir setups that introduce feed inconsistency and manual intervention overhead.
- Outcome: Consistent nutrient delivery and oxygen saturation across four 15-gallon (58L) vessels via integrated JET-STREAM® Vortex™ pump and venturi injector architecture.
- Replaces: Disconnected single-pot reservoir configurations, manual top-feed schedules, and uncoordinated drain-to-waste setups that create inter-plant variance.
- Environment: Controlled indoor cultivation spaces where feed precision, root-zone oxygen levels, and system serviceability are operational priorities.
FACTORY-AUTHORIZED DEALER — CANNAFULL SPECTRUM SOLUTIONS
Deployed in licensed commercial facilities across the United States.
Quick Spec: SKU BD100-0001 | 4-Pot DWC | 2-Row Configuration | 15 gal / 58L per vessel | JET-STREAM® Vortex™ pump | T304 Stainless clamps | 5″ spiral tubing | Push-fit feed connections
Precision Control in Any Space
Every cultivation operation that runs on disconnected equipment eventually pays for it — not in a single catastrophic event, but in the slow, compounding cost of variance. When reservoir levels drift between vessels, when oxygen delivery depends on how recently someone checked the pump, when your top-feed schedule is a manual approximation rather than an engineered constant, the plants in position one and the plants in position four are not receiving the same inputs. That gap — invisible on any single day, undeniable across a full cycle — is the real cost of equipment that was never designed to work as a unified system.
After deployment, the operational picture changes. Four vessels receive coordinated nutrient delivery from a single integrated reservoir circuit. Oxygen saturation at the root zone is not a variable — it is a designed output of the system's pump and injector architecture. Inspection covers allow visual confirmation of root health without disturbing the feed cycle. Drainage bases manage runoff without operator intervention. The system runs, the feed is consistent, and the variance that previously lived between pots is eliminated by design rather than managed by attention.
The mechanism behind that outcome is the integration of the JET-STREAM® Vortex™ pump with venturi injectors across a 2-row, 4-pot configuration — each vessel holding 15 gallons (58 liters) and connected via 5-inch spiral tubing with push-fit feed connections. T304 stainless steel clamps secure every junction point, eliminating the corrosion and joint failure that degrade lesser systems over time. Integrated filtration protects the pump and injectors from particulate contamination, and the water fill line removes the guesswork from reservoir management. In practical terms, the V-SYSTEM 4 Pot Kit delivers direct nutrient distribution and maximum oxygen saturation across four 58-liter vessels through a closed, pump-driven DWC circuit with push-fit irrigation connections and stainless-steel-secured tubing throughout.
Where This Belongs (and Doesn't)
The V-SYSTEM 4 Pot Kit is a self-contained Deep Water Culture irrigation system. Electrical infrastructure, environmental controls, and facility plumbing are operator-supplied and must comply with all applicable local, state, and federal codes. Cannafull Spectrum Solutions does not provide installation services. Consult a licensed contractor for facility integration work.
Designed For
- Indoor controlled cultivation spaces with stable ambient temperature and humidity
- Operators running 4-plant DWC cycles who require coordinated feed delivery across all vessels
- Facilities transitioning from manual top-feed or drain-to-waste configurations to a closed, pump-driven reservoir system
- Compact grow rooms where footprint efficiency and system serviceability must coexist
Not Designed For
- Outdoor or greenhouse environments where ambient contamination and temperature swings compromise reservoir stability
- Operations requiring more than four active vessels without supplemental system expansion
- Soil, coco, or media-based cultivation — this system is engineered exclusively for Deep Water Culture
- Facilities without a stable electrical supply capable of running the JET-STREAM® Vortex™ pump continuously
How It Works
The V-SYSTEM 4 Pot Kit operates on Deep Water Culture principles, meaning plant root systems are suspended directly in oxygenated, nutrient-rich solution rather than in any growing medium. The JET-STREAM® Vortex™ pump drives circulation through the system, maintaining active water movement that prevents nutrient stratification and supports consistent uptake across all four vessels. Venturi injectors are integrated into the circuit to introduce dissolved oxygen directly into the reservoir solution — a passive, mechanically reliable method that does not depend on air stones or separate aeration hardware that can fail independently.
The 2-row configuration positions two pots per row, with each vessel holding 15 gallons (58 liters) of nutrient solution. Feed connections use a push-fit architecture, which eliminates threaded fittings as a leak point and allows rapid disconnection for cleaning or component inspection without tools. The 5-inch spiral tubing maintains flow geometry through bends and routing changes without kinking or collapsing under pump pressure. T304 stainless steel clamps secure all tubing junctions — a material specification that resists the corrosive chemistry of nutrient solutions over extended operational periods where standard hardware would degrade and fail.
Integrated filtration upstream of the pump and injectors intercepts particulate matter before it can restrict flow or damage precision components. Inspection covers on each vessel allow visual root-zone assessment without breaking the feed circuit or disturbing the reservoir environment. Drainage bases manage solution runoff at the vessel level, containing overflow and directing it away from the root zone without operator intervention. The water fill line provides a reference point for consistent reservoir management, removing volume estimation from the maintenance routine. In practical terms, the V-SYSTEM 4 Pot Kit delivers a fully integrated DWC irrigation circuit — pump-driven oxygenation, push-fit feed connections, stainless-secured tubing, and passive filtration — across four 15-gallon (58L) vessels in a 2-row layout.
Commercial Assurance
Cannafull Spectrum Solutions is a factory-authorized dealer of the Alien V-SYSTEM product line. Every unit sold through this channel is sourced through authorized distribution, carries full manufacturer component integrity, and is supported by our pre-shipment verification process.
- Authorized Channel: Purchased through Cannafull Spectrum Solutions, your V-SYSTEM 4 Pot Kit is covered under the manufacturer's warranty terms as provided by Alien Hydroponics. Warranty period is as specified by the manufacturer at time of purchase — no warranty period is independently stated in available source data; confirm current terms with our team prior to ordering.
- Component Integrity: JET-STREAM® Vortex™ pump, T304 stainless clamps, venturi injectors, integrated filtration, drainage bases, inspection covers, and water fill line are all factory-included components — not aftermarket substitutions.
- Pre-Shipment Verification: Orders are dispatched within 3 business days following order confirmation and payment clearance.
- Support Access: Technical and operational support is available through Cannafull Spectrum Solutions for the life of the system.
System Integration
- Nutrient Solution Compatibility: The DWC reservoir circuit is compatible with standard hydroponic nutrient formulations; confirm pH and EC targets with your nutrient supplier for DWC-specific protocols.
- Electrical Requirements: The JET-STREAM® Vortex™ pump requires a continuous electrical supply — confirm pump draw against your facility's circuit capacity before installation. Electrical specifications are available from the manufacturer.
- Environmental Controls: Reservoir solution temperature directly affects dissolved oxygen levels in DWC systems; facility HVAC must maintain ambient conditions that keep solution temperature within the manufacturer's recommended operating range.
- Expansion Compatibility: The 2-row, 4-pot configuration is a self-contained unit; operators planning to scale beyond four vessels should consult Cannafull Spectrum Solutions regarding compatible Alien V-SYSTEM expansion options.
- Drainage Infrastructure: Integrated drainage bases manage vessel-level runoff; facility floor drainage must be capable of handling total system volume in the event of a full reservoir change or emergency drain.
Facility Integration Data
The following table provides a reference framework for operators evaluating multi-unit deployment of the V-SYSTEM 4 Pot Kit across a licensed facility. All figures are based on per-unit vessel capacity and pot count; electrical and infrastructure costs are facility-specific and must be calculated independently.
| Fleet Size | Total Active Vessels | Total Reservoir Capacity (gal) | Total Reservoir Capacity (L) | Infrastructure Note |
|---|---|---|---|---|
| 10 Units | 40 vessels | 600 gal | 2,320 L | 10 independent pump circuits; confirm electrical panel capacity |
| 20 Units | 80 vessels | 1,200 gal | 4,640 L | 20 independent pump circuits; dedicated sub-panel recommended |
| 50 Units | 200 vessels | 3,000 gal | 11,600 L | 50 independent pump circuits; licensed electrical contractor required for panel design |
Operator Field Notes
- Reservoir Temperature Management: DWC systems are sensitive to solution temperature — dissolved oxygen levels drop as water temperature rises. Monitor reservoir temperature continuously and address ambient heat sources before they become a root-zone problem.
- Push-Fit Connection Inspection: At each reservoir change, visually inspect all push-fit connections for seating integrity. A partially seated fitting will not leak immediately but will introduce air into the feed line under pump pressure over time.
- Venturi Injector Maintenance: Venturi injectors can accumulate mineral deposits from nutrient solution over extended run cycles. Include injector inspection and flush in your scheduled maintenance protocol — do not wait for visible flow restriction before servicing.
- Integrated Filtration Service Interval: The filtration component protects the JET-STREAM® Vortex™ pump from particulate damage. Establish a cleaning interval based on your nutrient solution's particulate load — higher-concentration or organic-supplement programs will require more frequent service.
- Stainless Clamp Torque: T304 stainless clamps maintain joint integrity across the tubing circuit. Check clamp tension after the first 72 hours of operation as tubing settles under pump pressure, and re-torque to manufacturer specification if any movement is detected.
- Inspection Cover Protocol: Use inspection covers for scheduled root-zone assessment rather than ad hoc checks. Frequent cover removal introduces light and ambient air to the reservoir environment — establish a fixed inspection cadence and document findings each cycle.
Operator FAQ
Q: What type of hydroponic method does the V-SYSTEM 4 Pot Kit use, and how does it differ from top-feed or drain-to-waste configurations?
A: The V-SYSTEM 4 Pot Kit operates on Deep Water Culture (DWC) methodology. In DWC, plant root systems are suspended directly in oxygenated, nutrient-rich solution — there is no growing medium, no top-feed drip schedule, and no drain-to-waste runoff cycle to manage. The JET-STREAM® Vortex™ pump maintains active circulation and the venturi injectors introduce dissolved oxygen into the solution continuously. This differs fundamentally from top-feed systems, where nutrient solution is delivered to the root zone on a timed schedule and drained away, and from drain-to-waste configurations, where solution is not recirculated. DWC keeps roots in constant contact with oxygenated nutrient solution, which supports accelerated uptake when the system is properly maintained.
Q: What is the reservoir capacity of each pot in the V-SYSTEM 4 Pot Kit?
A: Each of the four vessels in the V-SYSTEM 4 Pot Kit holds 15 gallons (58 liters) of nutrient solution. The system is configured in two rows of two pots each, giving operators four independent root zones within a single coordinated irrigation circuit. Total system reservoir capacity across all four vessels is 60 gallons (232 liters).
Q: What role do the venturi injectors play in the system, and do they require a separate air pump?
A: The venturi injectors are integrated into the feed circuit and use the pressure differential created by the JET-STREAM® Vortex™ pump's water flow to draw air into the solution — a passive oxygenation mechanism that does not require a separate air pump or air stone. This architecture reduces the number of independent components that can fail and eliminates the maintenance overhead associated with separate aeration hardware. The venturi injectors should be inspected and flushed periodically to prevent mineral deposit accumulation from restricting their function.
Q: Why are T304 stainless steel clamps specified for this system rather than standard hardware?
A: Nutrient solutions — particularly those with elevated EC levels or pH-adjusted chemistry — are corrosive to standard steel and zinc-plated hardware over time. T304 stainless steel is specified for its resistance to the oxidizing and acidic conditions present in active hydroponic circuits. Using standard hardware at tubing junctions introduces a degradation pathway that can result in clamp failure, joint loosening, and reservoir leaks across multi-cycle operational periods. The T304 specification is a long-term reliability decision, not a cosmetic one.
Q: Can the V-SYSTEM 4 Pot Kit be expanded to support more than four vessels?
A: The V-SYSTEM 4 Pot Kit (SKU BD100-0001) is a self-contained 4-pot, 2-row DWC configuration. It is not designed to have additional vessels added to its existing pump and feed circuit without engineering evaluation. Operators planning to scale beyond four active vessels should contact Cannafull Spectrum Solutions to discuss compatible Alien V-SYSTEM configurations that are engineered for larger plant counts — rather than attempting to extend the existing system beyond its designed parameters.
Q: What is the warranty coverage on the V-SYSTEM 4 Pot Kit purchased through Cannafull Spectrum Solutions?
A: The V-SYSTEM 4 Pot Kit is covered under the manufacturer's warranty terms as provided by Alien Hydroponics. No specific warranty period is independently stated in the available product source data. As a factory-authorized dealer, Cannafull Spectrum Solutions ensures that every unit is sourced through authorized distribution channels, which is a prerequisite for valid warranty coverage. Contact our team prior to ordering to confirm the current warranty terms applicable to your purchase.
Shipping & Logistics
- Shipping Territory: Cannafull Spectrum Solutions ships within the contiguous 48 United States only. Orders to Alaska, Hawaii, U.S. territories, or international destinations cannot be processed through this channel.
- Dispatch Timeline: Orders are dispatched within 3 business days following order confirmation and payment clearance. Delivery windows are carrier-dependent and will be communicated at time of shipment.
- Returns: Returns are accepted subject to the conditions outlined in the Cannafull Spectrum Solutions Return Policy. Items must be in original, uninstalled condition with all factory components present. Contact our team before initiating any return shipment.
- Restocking Fee: Returns of non-defective items are subject to a restocking fee of up to 25% per our Return Policy. Review full terms at cannafullspec.com/pages/return-policy before ordering.
For order status, shipping inquiries, or pre-purchase technical questions, contact Cannafull Spectrum Solutions directly at cannafullspec.com or via the contact methods listed on our website.
What's in the Box
The following components are confirmed as factory-included with the V-SYSTEM 4 Pot Kit (SKU BD100-0001) based on manufacturer source data:
- 4 x DWC vessels — 15 gallons (58 liters) each, configured in 2 rows of 2
- JET-STREAM® Vortex™ pump
- 5-inch spiral tubing
- T304 stainless steel clamps
- Push-fit feed connections
- Venturi injectors
- Drainage bases
- Inspection covers
- Integrated filtration component
- Water fill line
Note: Quantitative specifications (dimensions, individual component weights, tubing lengths) are not provided in available manufacturer source data. Nutrient solution, growing media, environmental controls, and electrical infrastructure are not included and are operator-supplied. Verify complete box contents against the packing list included with your shipment and report any discrepancies to Cannafull Spectrum Solutions within 48 hours of receipt.
Regional Compliance & Deployment Notes
- Licensing Jurisdiction: The V-SYSTEM 4 Pot Kit is a hydroponic irrigation system. Its purchase, possession, and use are subject to the cultivation licensing requirements of the state and municipality in which it is deployed. Operators are solely responsible for confirming that their facility holds all required licenses prior to system deployment.
- Electrical Compliance: Pump and system electrical connections must be installed in compliance with the National Electrical Code (NEC) and any applicable state or local electrical codes. Cannafull Spectrum Solutions does not provide electrical installation services.
- Water and Drainage Regulations: Nutrient solution discharge is subject to local wastewater and environmental regulations. Operators must confirm that their drainage and disposal practices comply with applicable state and municipal requirements before commissioning the system.
- Facility Inspection Readiness: All system components, reservoir configurations, and drainage infrastructure should be documented as part of the facility's standard operating procedures to support regulatory inspections where required by state licensing authorities.
- Interstate Commerce: This product is sold and shipped within the contiguous 48 United States only. State-specific restrictions on hydroponic equipment or cultivation infrastructure, if any, are the operator's responsibility to identify and comply with prior to purchase.
Cannafull Spectrum Solutions provides this compliance information as a general reference only. It does not constitute legal advice. Operators should consult qualified legal counsel and their state licensing authority to confirm all applicable requirements for their specific facility and jurisdiction. Regulatory frameworks governing licensed cultivation vary by state and are subject to change.
