Alien Hydroponics V-SYSTEM 15 盆栽套装

Quick Spec: SKU BD100-0315  |  15 V-POTs (15 gal / 58L each)  |  3 Rows  |  241 gal / 912.3L total fluid volume  |  Pot size options: 5 gal / 20L or 9.5 gal / 36L  |  JET-STREAM® Vortex™ pump included

Precision Control in Any Space

Every inconsistent result in a recirculating system traces back to the same root failure: equipment that cannot maintain solution uniformity across every pot, every cycle, every day. When reservoir management is manual, dissolved oxygen levels drift between irrigation events. When fittings are undersized or mismatched, flow rates diverge across rows and the plants at the end of the line receive a fundamentally different solution than the plants at the inlet. That variance is silent — it does not announce itself in a single failed crop, it bleeds yield across every run, compounding into a structural gap between what your inputs cost and what your canopy actually produces.

After deployment, the operational picture changes at the system level. All 15 plants draw from a unified 241-gallon / 912.3-liter reservoir maintained by a float valve that handles automatic top-off without operator intervention. Nutrient solution circulates continuously through the recirculating deep water culture architecture, meaning every root zone receives the same dissolved oxygen concentration and the same nutrient profile simultaneously. The header and pump can be positioned outside the grow room entirely, or configured for maximum compactness inside it — the layout adapts to the space rather than forcing the space to accommodate the equipment. An aisle can be created down the center of the three rows, giving operators complete access to every plant without disturbing adjacent canopy.

The mechanism behind that operational stability is a purpose-built component stack. The JET-STREAM® Vortex™ pump drives circulation through 5-inch spiral tubing and 5-inch Dual-Flow™ fittings — oversized hydraulic pathways that eliminate the flow restriction that causes nutrient stratification in smaller-diameter systems. Venturi injectors oxygenate the solution in motion, removing the need for a separate air pump and eliminating one more variable from the maintenance schedule. Total-drainage bases allow complete reservoir evacuation for cleaning cycles without disassembly. T304 stainless clamps and push-fit feed connections handle the mechanical interface between components, and integrated filtration protects the pump and fittings from particulate accumulation. Each V-POT holds 15 gallons / 58 liters, and the system accepts either 5-gallon / 20L or 9.5-gallon / 36L pot inserts depending on cultivar and canopy strategy. In practical terms, the V-SYSTEM 15 Pot Kit delivers recirculating RDWC irrigation to 15 plants across a 3-row footprint with a 241-gallon / 912.3-liter total fluid volume and zero air pump dependency.

Where This Belongs (and Doesn't)

The V-SYSTEM 15 Pot Kit is a hydraulic irrigation and reservoir management system. Electrical supply, environmental controls, lighting infrastructure, and nutrient dosing automation are operator-supplied and fall outside the scope of this kit. Verify that your facility's water supply, drainage capacity, and floor load rating are compatible with a filled system volume of 241 gallons / 912.3 liters before installation.

How It Works

The V-SYSTEM 15 Pot Kit operates as a recirculating deep water culture system — a closed-loop hydraulic architecture in which nutrient solution is continuously circulated from a central reservoir through all 15 V-POTs and returned, maintaining solution homogeneity across every plant site without relying on timed top-feed events or passive gravity drainage. The JET-STREAM® Vortex™ pump is the circulation engine. It drives solution through 5-inch spiral tubing — a hydraulic diameter specification that sustains adequate flow velocity across all three rows without pressure drop-induced stratification. At each V-POT, 5-inch Dual-Flow™ fittings manage both the inlet and return pathways, and Venturi injectors introduce dissolved oxygen into the moving solution stream, eliminating the need for a separate air pump while maintaining oxygen saturation at the root zone.

Each V-POT holds 15 gallons / 58 liters of solution. Across 15 pots in a 3-row configuration, the system maintains a total fluid volume of 241 gallons / 912.3 liters. A float valve manages automatic top-off, compensating for evapotranspiration losses and maintaining reservoir level without manual intervention between scheduled nutrient changes. Total-drainage bases allow complete system evacuation — every pot and the main reservoir can be drained fully for cleaning and solution replacement without disassembly of the plumbing network. T304 stainless clamps secure all tubing connections at the mechanical interface, and push-fit feed connections allow the system to be assembled and reconfigured without specialized tooling. Integrated filtration upstream of the pump protects the JET-STREAM® Vortex™ from particulate accumulation that would otherwise degrade flow rate over time. Inspection covers provide visual access to root zones and solution levels without disturbing the canopy above. In practical terms, the V-SYSTEM 15 Pot Kit maintains a continuously oxygenated, recirculating nutrient solution across 15 plant sites in a 3-row layout spanning a total fluid capacity of 241 gallons / 912.3 liters, with automated top-off and full-system drainage capability built into the base configuration.

Configuration Decoder

System Integration

• Reservoir Positioning: The header and JET-STREAM® Vortex™ pump can be located outside the grow room or tent, keeping the cultivation footprint clear of mechanical equipment and simplifying access for nutrient management and maintenance.
• Nutrient Dosing Integration: The centralized 241-gallon / 912.3-liter reservoir is the single point of solution management — compatible with inline dosing systems, EC/pH monitoring probes, and automated nutrient controllers that operators supply independently.
• Drainage Infrastructure: Total-drainage bases require a floor drain or collection system capable of handling full reservoir evacuation. Confirm drainage capacity before installation.
• Aisle Access: The 3-row layout supports a center-aisle configuration, enabling complete plant access without canopy disruption — a relevant factor for training, inspection, and harvest logistics in space-constrained rooms.
• Pot Insert Compatibility: The system accepts 5-gallon / 20L or 9.5-gallon / 36L pot inserts. Select insert size based on cultivar root mass requirements and canopy management protocol.

Facility Integration Data

The table below provides a fleet-scale reference for operators evaluating the V-SYSTEM 15 Pot Kit across multiple rooms or expansion phases — use it to project total plant capacity, combined fluid volume under management, and the number of system units required to fill a given canopy target.

Operator Field Notes

• Measure your room before selecting a variant. The four layout variants (MIH at 122", MOL at 141⅛", MOR at 139⅝", MSP at 138") differ only in length. Width is fixed at 65¾" across all variants. Confirm your floor plan accommodates the selected footprint plus aisle clearance before ordering.
• Float valve maintenance is a scheduled task, not an optional one. The automatic top-off float valve maintains reservoir level between nutrient changes. Inspect and calibrate it on a defined schedule — a drifting float valve will introduce the same solution-level variance the system is designed to eliminate.
• Integrated filtration requires periodic service. The upstream filter protecting the JET-STREAM® Vortex™ pump will accumulate particulate over time. Establish a cleaning interval based on your water source quality and nutrient formulation to prevent flow rate degradation.
• Total-drainage capability is an operational asset — use it. Full reservoir evacuation between cycles is the most reliable method for preventing pathogen and salt accumulation. The total-drainage bases make this practical; build it into your standard operating procedure.
• Pot insert selection affects root zone dynamics. The 5-gallon / 20L insert suits shorter production cycles and tighter canopy spacing. The 9.5-gallon / 36L insert provides greater root volume for longer vegetative periods or larger cultivars. Align insert selection with your production schedule before the system ships.
• Header and pump placement should be decided before installation. Routing the header and pump outside the grow room simplifies maintenance access and reduces heat load inside the cultivation space. Plan the plumbing path before the system is assembled.

Operator FAQ

Shipping & Logistics

• Shipping Jurisdiction: Cannafull Spectrum Solutions ships within the contiguous 48 United States only. Orders outside this jurisdiction cannot be processed.
• Freight Classification: The V-SYSTEM 15 Pot Kit ships as a multi-component kit. Due to system volume and component count, freight shipment is standard. Confirm delivery access (dock, lift gate, or ground-level) at your facility before order placement. Specific shipping lead times and carrier information will be provided at checkout or upon request.
• Returns: Returns are subject to the Cannafull Spectrum Solutions Return Policy. Defective units are handled under manufacturer warranty terms. Non-defective returns must be initiated within the return window specified in the Return Policy and must be in original, uninstalled condition.
• Restocking Fee: Returns of non-defective items are subject to a restocking fee of up to 25% per our Return Policy. Review full terms at cannafullspec.com/pages/return-policy before ordering.

Questions before ordering? Contact Cannafull Spectrum Solutions at support@cannafullspec.com or visit cannafullspec.com for pre-purchase technical consultation.

What's in the Box

The following components are confirmed included with every V-SYSTEM 15 Pot Kit (SKU BD100-0315) regardless of variant selected:

• 15 x V-POT vessels (15 gal / 58L each)
• JET-STREAM® Vortex™ pump
• 5" spiral tubing
• 5" Dual-Flow™ fittings
• Venturi injectors
• Total-drainage bases
• Float valve for automatic top-off
• Water fill line
• Inspection covers
• Integrated filtration assembly
• T304 stainless clamps
• Push-fit feed connections
• Heavy-duty structural components

Note: Nutrient solution, growing media, pot inserts (5 gal / 20L or 9.5 gal / 36L), environmental controls, lighting, and dosing automation are not included and must be sourced independently. Component list is based on manufacturer-published specifications for SKU BD100-0315. Verify final kit contents against packing documentation upon receipt. Contact Cannafull Spectrum Solutions immediately if any component is missing or damaged.

Regional Compliance & Deployment Notes

• Jurisdiction: The V-SYSTEM 15 Pot Kit is available for purchase and delivery within the contiguous 48 United States through Cannafull Spectrum Solutions. This product is not available for shipment to addresses outside the contiguous U.S.
• Regulatory Compliance: The V-SYSTEM 15 Pot Kit is a hydroponic irrigation and reservoir management system. It contains no controlled substances and is not subject to cannabis-specific regulatory restrictions at the equipment level. Operators are responsible for ensuring that their cultivation facility holds all required state and local licenses and that system installation complies with applicable building, plumbing, and water use regulations in their jurisdiction.
• Water Use and Drainage: Operators in jurisdictions with water use reporting requirements or commercial drainage regulations should confirm that a 241-gallon / 912.3-liter recirculating system is compliant with local water authority requirements before installation.
• Facility Licensing: Cannafull Spectrum Solutions sells to licensed commercial cultivation operators across the United States. It is the operator's responsibility to maintain current facility licensure and to ensure that equipment deployment is consistent with the terms of their operating license.
• Technical Support: U.S.-based technical support, stocking, and customer service are available through Cannafull Spectrum Solutions for all V-SYSTEM deployments within the contiguous United States.

Compliance requirements vary by state and municipality. The information provided here is general operational guidance only and does not constitute legal or regulatory advice. Operators should consult qualified legal counsel and their state licensing authority to confirm that equipment installation and operation meets all applicable requirements in their jurisdiction. Cannafull Spectrum Solutions assumes no liability for regulatory non-compliance arising from equipment installation or use.
